Model QQC30000A-X QQC30000C-X
Basic electrical properties
AC input voltage 323 ~ 473Va.c.; 380Va.c. (type)
AC input frequency 45 ~ 55Hz; 50Hz (type)
Output power 0-30KW
Output voltage 200 ~ 1000Vd.c.
Constant power range 300 ~ 1000Vd.c.
Output current 0 ~ 100A
Power factor 0.99 (full load)
Peak efficiency 93%
Reference Standards GB/T 20234.1—2015, GB/T 20234.3—2015, GB/T 27930—2015, GB/T 18487.1—2015, NB/T 33001—2018
Features
Access mode Three-phase four-wire
Intelligent control One-key start Mobile applet control, intelligent anti-theft
Protection design Overvoltage protection, undervoltage protection, overload protection, short circuit protection, grounding protection, overtemperature protection, low temperature protection, lightning protection
Electric shock protection Double insulation
Communication interface None 4G
Noise less than 65dB
Cooling method Forced air cooling
Use environment
IP level IP54 protection level, (recommended to install canopy)
Working temperature -30-50℃; intelligent anti-over temperature protection
Relative humidity 5% to 95%
Altitude 2000m
Atmospheric pressure 70 ~ 106KPa
Applicable environment Large shopping malls, office buildings, residential quarters and other ground and underground parking lots
Mechanical properties
Body size 500mm*700mm*145mm
Package size 614mm*942mm*370mm
Weight 50kG
Gun cord length 5 meters
Input cable length non-standard
